4.6 Load Transient Response

The TPS562219AEVM-663 response to load transient is shown in Figure 4-6. The current steps and slew rates are indicated in the figures. Total peak-to-peak voltage variation is as shown.

GUID-32E5EAC3-77A8-46B5-82F2-C03FDC686262-low.gifFigure 4-6 TPS562219AEVM-663 Load Transient Response, 25% to 75% Load Step
