6.2 Tape and Reel Information

Device Package
Type		 Package Drawing Pins SPQ Reel
Diameter (mm)		 Reel
Width W1 (mm)		 A0
(mm)		 B0
(mm)		 K0
(mm)		 P1
(mm)		 W
(mm)		 Pin1
Quadrant
DRV3255EPAPRQ1 HTQFP PAP 64 1000 330.0 24.4 13.0 13.0 1.5 16.0 24.0 DRV3255
Device Package Type Package Drawing Pins SPQ Length (mm) Width (mm) Height (mm)
DRV3255EPAPRQ1 HTQFP PAP 64 1000 10.0 10.0 1.0
