4.4 Shut-Down

The TPS562202EVM shut-down waveform relative to VIN is shown in Figure 4-4.

GUID-20200819-CA0I-VHFD-9ZF7-DRKQDZ23VFZF-low.gif Figure 4-4 Shut-Down Relative to VIN, IOUT = 2 A

The TPS562202EVM shut-down waveform relative to EN is shown in Figure 4-5.

GUID-20200819-CA0I-S8M5-7VPW-5XKPZ7KSKQQL-low.gif Figure 4-5 Shut-Down Relative to EN, IOUT = 2 A
