2.3 Package Symbolization and Revision Identification

Figure 2-1 provides an example of the 2805x package symbolization and defines each of the markings. The device revision can be determined by the symbols marked on the top of the package as shown in Figure 2-1. Some prototype devices may have markings different from those illustrated. Figure 2-2 shows an example of the device nomenclature.

GUID-AC358EB4-4B5E-43FA-8208-F8E6CDA05218-low.gif Figure 2-1 Example of Package Symbolization
Table 2-1 Determining Silicon Revision From Lot Trace Code
PACKAGE MARKING CODE SILICON REVISION REVISION ID
Address: 0x0883		 COMMENTS
Blank Indicates Revision 0(1) 0x0000 This silicon revision is available as TMX.
A Indicates Revision A(1) 0x0000 This silicon revision is available as TMS.
(1) Boot-ROM contents changed between Rev. 0 silicon and Rev. A silicon. For more details, see the TMS320x2805x Real-Time Microcontrollers Technical Reference Manual.
GUID-87928562-E9D6-4DEB-9833-14DBC9B44BCE-low.gif Figure 2-2 Device Nomenclature
