6.9 System Mounting Interface Loads

PARAMETER MIN NOM MAX UNIT
Maximum system mounting interface load to be applied to the: Thermal Interface Area (see Figure 6-15) 60 N
Clamping and Electrical Interface Area (see Figure 6-15) 110 N
GUID-20210309-CA0I-7KKR-QZJF-4X4KH2ZSFBP2-low.gif Figure 6-15 System Interface Loads
