3.1.14.1 Write Parameters

Table 3-23 describes the write parameters.

Table 3-23 Write Parameters
MSBByte 1LSB
b7b6b5b4b3b2b1b0
Parameter Byte
b(7:3)Reserved
b(2)Short axis image flip:
  • 0: Image not flipped.
  • 1: Image flipped.
b(1)Long axis image flip:
  • 0: Image not flipped.
  • 1: Image flipped.
b(0)

Reserved

GUID-D312D8D4-BFEF-4BCE-AAC8-1306E25C46A1-low.gifFigure 3-10 Long-Axis Flip

Figure 3-11 shows the short-axis flip.

GUID-85F02840-ECA8-43EE-AF75-66004443CC24-low.gifFigure 3-11 Short-Axis Flip
