6.1 Pin Diagram

Figure 6-1 shows the pin locations for the 161-pin FCBGA package. Figure 6-2, Figure 6-3, Figure 6-4, and Figure 6-5 show the same pins, but split into four quadrants.

IWR1843 Pin Diagram Figure 6-1 Pin Diagram
IWR1843 Top Left Quadrant Figure 6-2 Top Left Quadrant
IWR1843 Top Right Quadrant Figure 6-3 Top Right Quadrant
IWR1843 Bottom Left Quadrant Figure 6-4 Bottom Left Quadrant
IWR1843 Bottom Right Quadrant Figure 6-5 Bottom Right Quadrant
