5.1.1.2 AC-MB USB Audio Setting

The AC-MB is detected by the OS as an audio device with the name TI USB Audio UAC2.0. Figure 5-2 shows the AC-MB audio setting for the USB mode of operation.

TAA3040 AC-MB USB Audio Setting Figure 5-2 AC-MB USB Audio Setting
