4.6 External I2C Input

GUID-AE7FA4EE-9A2F-46A8-92F8-B4E8275ABE3B-low.gifFigure 4-4 External I2C Input

The DV2625 can be controlled by an external I2C source. Attach the external controller to the I2C header at the top of the board; be sure to connect SDA, SCL and GND from the external source.
