Spur/Noise Floor Level

For Spur level measurements, a continuous tone at 77 GHz is transmitted and the received signal is analyzed with 524288 samples for the presence of the PMIC switching frequency spur at ~4 MHz. The Rx gain is set at 48dB with an observation that PMIC spur level tracks the Rx gain.

GUID-BDCF26D7-A73F-4F45-B55C-8CDC72CE36D6-low.gifFigure 4-6 LDO Scheme –Spur Level
Note:

No PMIC switching Frequency (approximately 4 MHz) Spur seen.

GUID-C6DEB268-ADC5-43C1-ADE1-6738212E737F-low.gifFigure 4-7 LDO Scheme - Noise Floor With Tx –OFF
GUID-521D0CC1-01E2-411B-8DCE-D51FC5E61DA5-low.gifFigure 4-8 LC Filter Scheme – Spur Level
Note:

PMIC spur is observed at -84.53 dBFS at RX gain of 48dB.

GUID-C6DEB268-ADC5-43C1-ADE1-6738212E737F-low.gifFigure 4-9 LC Filter Scheme - Noise Floor With Tx –OFF
