1.2 USB Interface Application in IVI

The USB interface is increasingly used in IVI systems for various functions, including media playback, device charging, and data transfer due to the highly standardized scalability specifications. This not only supports users to connect personal electronic devices, but also supports the communication between SoC and other IVI peripherals such as touchscreen, button, camera, and speakers. The TI C2000 real time MCU TMS320F28P55x has a variety of communication interface integration, including PMBus, I2C interfaces, CAN-FD, USB 2.0 integrates MAC + PHY, SPI, SCI, and LIN to support the different communication bridges to the USB. One possible USB connection structure in the IVI is shown in Figure 1-1.

USB Connection Structure in IVI Figure 1-1 USB Connection Structure in IVI
