B.31 MSP-TS430PN80B

GUID-0A93B4BF-5D5B-43A2-911B-411A039E3596-low.gifFigure 4-62 MSP-TS430PN80B Target Socket Module, Schematic
GUID-DFDB197C-2175-448C-9325-C9831DF35808-low.gifFigure 4-63 MSP-TS430PN80B Target Socket Module, PCB
Table 4-32 MSP-TS430PN80B Bill of Materials
PositionRef DesNo. per BoardDescriptionDigi-Key Part No.Comment
1PCB190.0 x 92.5 mm"MSP-TS430PN80B" Rev. 1.02 layers, blue solder mask
2JP1, JP2, JP9, JP13, JP14, JP1562-pin header, male, THSAM1035-02-NDplace jumper on header
3JP17, JP1822-pin header, male, THSAM1035-02-NDplace jumper on one side of header
4JP10, JP1122-pin header, male, THSAM1035-02-NDDNP, keep pads free of solder
5J113-pin header, male, THSAM1035-03-NDplace jumpers on pins 1-2
6JP3, JP4, JP5, JP6, JP7, JP8, JP1673-pin header, male, THSAM1035-03-NDplace jumpers on pins 2-3
7J213-pin header, male, THSAM1035-03-ND
8R2, R5, R6, R8, R950R, 0805541-0.0ATR-NDDNP
9R3, R12, R1330R, 0805541-0.0ATR-ND
10C511.1nF, CSMD0805490-1623-2-ND
11C3, C721uF/10V, CSMD0805490-1702-2-ND
12R7, R15210k, 0805541-10KATR-ND
13R4147k, 0805541-47KATR-ND
14C4, C6, C10, C114100nF, CSMD0805490-1666-1-ND
15R11330R, 0805541-330ATR-ND
16R10, R112330R, 0805541-330ATR-NDDNP
17R14147k, 0805541-47KATR-NDDNP
18C1, C2, C8, C94DNP, CSMD0805DNP
19SW21EVQ-11L05RP8079STB-NDDNP, keep pads free of solder
20SW11EVQ-11L05RP8079STB-NDDNP, keep pads free of solder
21TP1, TP22Test pointDNP, keep pads free of solder
22BSL110-pin connector, male, THHRP10H-ND
23JTAG114-pin connector, male, THHRP14H-ND
24U11Socket IC201-0804-014Manuf. Yamaichi
25MSP device1MSP430FR5994DNP: Not enclosed in kit
26Q11DNP: MS3V-TR1 (32768kHz, 20ppm, 12.5pF)depends on applicationMicro Crystal, DNP, enclosed in kit, keep vias free of solder
